AK7636BS
(Ventilation - Range Hoods)
Titan challenges the definition of pro-style hoods with its impressive size, powerful blower, and stunning good looks. Featuring Zephyr’s PowerWave™ technology, Titan features a 750-CFM blower with the option to combine two blowers together to achieve 1,300 CFM. Its unique aerodynamic blades improve efficiency with unparalleled quiet operation. The ultimate workhorse in the kitchen, Titan is available up to 60 inches and features pro baffle filters and LumiLight LED lighting.
Ask an Expert
ACT™ CONTROL TECHNOLOGY
Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with local codes and regulations.
POWERWAVE™ 3-PHASE BLOWER TECHNOLOGY
Delivers best-in-class performance with unparalleled quiet operation. It provides more power while minimizing noise and improving efficiency.
| GENERAL | |
|---|---|
| Series Name | Pro Titan |
| Blower Included | Yes |
| Airflow | 750 CFM |
| Style | Chimney |
| Color | Stainless Steel |
| Installation | Wall Mount |
| FEATURES | |
| Technologies |
• Airflow Control Technology™ (ACT™) • PowerWave™ Technology |
| Ducting Information |
• Vertical Single Internal Blower: 8" Round • Horizontal Single Internal Blower: 8" Round • Vertical Dual Internal Blower: 10" Round • Horizontal Dual Internal Blower: 10" Round |
| Speeds |
• Speed Levels : 6** • Blower CFM (Min. - Max.): 200 - 750 • ACT 590 CFM (Min. - Max.)*: 200-590 • ACT 390 CFM (Min. - Max.)*: 200-390 • ACT 290 CFM (Min. - Max.)*: 200-290 • Sones (Min. - Max.): 0.5 - 7 • *ACT™ only available with a single internal blower • **When ACT™ is enabled the number of fan speeds will be reduced to maximum 3 speeds |
| Additional Information |
• Electronic LCD • Auto Delay-Off • CleanAir Function • Directional Lighting: LumiLight LED, 6W x2 • Dual-Level Lighting • Filters: Pro Baffle x2 • Grease Collection Tray • Duct Cover Extension Option |
| ELECTRICAL INFORMATION | |
| Information |
• AC POWER (Single Blower): 120V, 60Hz at Max. 5A • AC POWER (Dual Blower): 120V, 60Hz at Max. 8A |
| CERTIFICATIONS AND APPROVALS | |
| Information | ADA Compliant with remote accessory |
| ACCESSORIES | |
| Optional |
• Wireless Remote Control: 14000005 • Dual Internal Blower: PBD-1300B • Duct Cover Extension: Z1C-0076 • Stainless Steel Telescopic Backsplash: AK1716/AK1712 • Make-Up Air Kit (Single Blower): MUA008A • Make-Up Air Kit (Dual Blower): MUA010A |
| DIMENSIONS | |
| Class Width | 36" |
| Width | 36 inch(es) / 91.44 cm |
| Height | 14.31 inch(es) / 36.35 cm |
| Depth | 24 inch(es) / 60.96 cm |
| Additional Dimensions | Mounting Height Range: 24" - 36" |
| WARRANTY | |
| Warranty |
• 3 Years Limited on Parts • 1 Year Limited Labor |
| UPC | |
| UPC# | 646328010491 |
