DPH36652UC
(Ventilation - Range Hoods)
Bosch 36" under cabinet Professional design, ventilation wall hood. This hood features a 600 CFM blower, two incandescent lights, dishwasher safe aluminum mesh filters and two power levels.
Ask an Expert
| GENERAL | |
|---|---|
| Series Name | 800 |
| Blower Included | Yes |
| Airflow | 600 CFM |
| Style | Standard |
| Color | Stainless Steel |
| Manufacturer Color | Stainless Steel |
| Installation | Under-Cabinet |
| FEATURES | |
| Dishwasher-Proof Filters | Yes |
| Ducting Information |
• Diameter of air duct (in.) top: 8" • Diameter of air duct (in.) back: 8" • Convertable: Ducted / Recirculating • Recirculation Option Available • Top or Rear Venting Options |
| Speeds | 2 Speeds |
| Additional Information |
• Brushed stainless steel finish • 2 incandescent lights, 80 W • Two power levels • Quickly and quietly clears the air of smoke and odor • Dishwasher-safe mesh filters • Easy to use controls • 2-stage speed settings • Approval certificates: CSA, UL |
| ELECTRICAL INFORMATION | |
| Information |
• 253 W • 120 V • 60 Hz |
| ACCESSORIES | |
| Optional |
• Replacement charcoal filter: DHZ3052UC • Recirculation kit DRZ3652UC (adds 4" to height of appliance) |
| DIMENSIONS | |
| Class Width | 36" |
| Width | 36 inch(es) / 91.44 cm |
| Height | 11 inch(es) / 27.94 cm |
| Depth | 23 inch(es) / 58.42 cm |
| Weight | 34 lb(s) / 15.42 kg |
| Additional Dimensions | Required distance above cooktops/ranges: 30"/30" |
| SHIPPING DIMENSIONS | |
| Weight | 47.99 lb(s) / 21.77 kg |
| WARRANTY | |
| Warranty | Limited 1 Year Parts and Labor |
| UPC | |
| UPC# | 825225884446 |
