VCBB5363ELCS
(Refrigerators - Bottom Freezer)
This 36-inch wide, Viking bottom-freezer refrigerator features ProChill™ temperature management, LED lighting, Spillproof Plus™ shelves with Nano technology and adjustable Humidity Zone™ drawers.
Ask an Expert
FILTER-FREE FRESHNESS
The Plasmacluster™ Ion Air Purifier uses ions to eliminate airbourne bacteria and mold spores, remove odors and enhance food preservation. Plasmacluster™ is a trademark of Sharp Corporation.
LED LIGHTING
Bright, energy-efficient LED lighting from top and sidewalls.
METAL DOOR BINS
Metal door bins provide enduring performance to securely store heavy items.
PROCHILL™ TEMPERATURE MANAGEMENT
ProChill™ Temperature Management System with variable speed DC Overdrive™ compressor. Single compressor system includes the quietest compressor available. Electronic controls provide precise temperature management with digital readout.
ROBUST DURAHINGE™
Robust DuraHinge™ allows optimal door rotation and maximum durability.
SPILLPROOF PLUS™ SHELVES
Spillproof Plus™ Shelves with Nano technology create an invisible barrier to contain spills.
| GENERAL | |
|---|---|
| Series Name | Professional 5 Series |
| Refrigerator Type | Bottom Freezer |
| Installation Type | Built-In |
| Counter-Depth | No |
| Door Hinge | Left |
| Color | Black |
| Manufacturer Color | Cast Black |
| CAPACITY | |
| Total | 20.4 cu. ft. / 0.58 cu. m. |
| Refrigerator | 15.3 cu. ft. / 0.43 cu. m. |
| Freezer | 5.1 cu. ft. / 0.14 cu. m. |
| REFRIGERATOR FEATURES | |
| Technologies |
• ProChill™ Temperature Management • Adjustable Humidity Zone™ Drawers • Variable Speed DC Overdrive™ Compressor • Odor Eliminator™ Evaporator • Super Clog Resistant™ Condenser • Plasmacluster™ Ion Air Purifier • Spillproof Plus™ Shelves |
| Digital Display | Yes |
| Door Alarm | Yes |
| Frost Free | Yes |
| Interior Light | Yes |
| Crisper Drawers | Yes |
| Deli Drawer/Meat | Yes |
| Gallon Door | Yes |
| Additional Information |
• Two Deli Drawers with Soft-Close Slides • Additional Space for Large Pizza Box Storage • Two In-the-Door Dairy Compartments with Covers • Four Patented (Three Are Adjustable) Aluminum Door Bins Securely Store Heavy Items |
| FREEZER FEATURES | |
| Additional Freezer Information |
• Full-Extension Main Freezer Compartment • Opens Quietly and Easily, With Ball-bearing Rollers Which Glide-On a Steel Track • Positive Self-Closing Feature Ensures a Good Seal • Upper Freezer Basket Slides Independently of Main Freezer Compartment • Adaptive Defrost Controls the Timing of the Defrost Periods, Instead of an Electromechanical Defrost Timer • Extends to 96 Hours – Improves Food Storage Because the Unit Defrosts Less Often |
| ICE AND WATER | |
| Ice System | Interior |
| Water System | None |
| Dispenser Features | Factory-Installed Automatic Ice Maker |
| ELECTRICAL INFORMATION | |
| Information |
• 115 V • 60 Hz • 15 A |
| ACCESSORIES | |
| Optional | Flush Mount Trim Kit - PBIRFTKSS |
| DIMENSIONS | |
| Class Width | 35" to 37.9" |
| Class Height | 70" and More |
| Width | 36.02 inch(es) / 91.5 cm |
| Height (With Hinge) | 82.76 inch(es) / 210.2 cm |
| Depth (Without Handles) | 24.02 inch(es) / 61.0 cm |
| Depth (With Handles) | 26.5 inch(es) / 67.3 cm |
| Additional Dimensions |
• Cutout Width : 35-5/8" (90.5 cm) Min. to 35-3/4" (90.8 cm) Max. • Cutout Height: 82-7/8" (210.5 cm) Min. to 84-1/16" (213.5 cm) Max. • Cutout Depth: 24" (61.0 cm) Min. |
| SHIPPING DIMENSIONS | |
| Weight | 565 lb(s) / 256.28 kg |
| WARRANTY | |
| Warranty |
• Two-Year Full – Complete Product • Six-Year Full – Sealed Refrigeration System • Ninety-Day Full – Cosmetic Parts Such as Glass, Painted Items, and Decorative Items • Twelve-Year Limited – Sealed Refrigeration System (Includes Compressor, Condenser, Dryer/Strainer, Evaporator, and Connecting Tubing) |
